Oxidized ATP (oATP) trisodium salt is a broad-spectrum P2 receptor blocker/inhibitor. Oxidized ATP trisodium salt irreversibly antagonizes P2X7R activation. Oxidized ATP trisodium salt inhibits C-reactive protein (CRP)-induced NLRP3 inflammasome activation. Oxidized ATP (oATP) trisodium salt is useful in atherosclerosis research.

Physicochemical Properties

Molecular Formula	C10H14N5O13P3.NA
Molecular Weight	528.15506
Exact Mass	527.969
CAS #	71997-40-5
PubChem CID	57369844
Appearance	White to off-white solid powder
Hydrogen Bond Donor Count	5
Hydrogen Bond Acceptor Count	17
Rotatable Bond Count	12
Heavy Atom Count	32
Complexity	796
Defined Atom Stereocenter Count	0
SMILES	C1=NC(=C2C(=N1)N(C=N2)C(C=O)OC(COP(=O)(O)OP(=O)(O)OP(=O)(O)O)C=O)N.[Na]
InChi Key	KOCWSVPHHGJWHA-UHFFFAOYSA-N
InChi Code	InChI=1S/C10H14N5O13P3.Na/c11-9-8-10(13-4-12-9)15(5-14-8)7(2-17)26-6(1-16)3-25-30(21,22)28-31(23,24)27-29(18,19)20;/h1-2,4-7H,3H2,(H,21,22)(H,23,24)(H2,11,12,13)(H2,18,19,20);
HS Tariff Code	2934.99.9001
Storage	Powder-20°C 3 years 4°C 2 years In solvent -80°C 6 months -20°C 1 month Note: Please store this product in a sealed and protected environment, avoid exposure to moisture.
Shipping Condition	Room temperature (This product is stable at ambient temperature for a few days during ordinary shipping and time spent in Customs)

Biological Activity

Targets	NLRP3 inflammasome P2X7 Receptor
ln Vitro	In HUVEC, CRP (20 μg/mL, 24 hours)-induced caspase-1 activation and IL-1β maturation is inhibited by oxidized ATP trisodium salt (100 μM, 1 hour) [1].
ln Vivo	In B6 mice, oxidized ATP (300 μg/mouse, intraperitoneally, twice a week) and trisodium salt reduce experimental autoimmune uveitis (EAU)[2].
Animal Protocol	Animal/Disease Models: Induced mouse experimental autoimmune uveitis (EAU)[2] Doses: 300 μg/mouse Route of Administration: ip Experimental Results: demonstrated almost undetected EAU, as shown by fundoscopic and pathologic examination. diminished serum IL-17 level. Mitigated the autoreactive T cell response.
References	[1]. CRP-Induced NLRP3 Inflammasome Activation Increases LDL Transcytosis Across Endothelial Cells. Front Pharmacol. 2019 Jan 30;10:40. [2]. Blockade of Extracellular ATP Effect by Oxidized ATP Effectively Mitigated Induced Mouse Experimental Autoimmune Uveitis (EAU). PLoS One. 2016 May 19;11(5):e0155953.

Solubility Data

Solubility (In Vitro)

May dissolve in DMSO (in most cases), if not, try other solvents such as H2O, Ethanol, or DMF with a minute amount of products to avoid loss of samples

Solubility (In Vivo)

Note: Listed below are some common formulations that may be used to formulate products with low water solubility (e.g. < 1 mg/mL), you may test these formulations using a minute amount of products to avoid loss of samples. Injection Formulations (e.g. IP/IV/IM/SC) Injection Formulation 1: DMSO : Tween 80： Saline = 10 : 5 : 85 (i.e. 100 μL DMSO stock solution → 50 μL Tween 80 → 850 μL Saline) *Preparation of saline: Dissolve 0.9 g of sodium chloride in 100 mL ddH ₂ O to obtain a clear solution. Injection Formulation 2: DMSO : PEG300 ：Tween 80 : Saline = 10 : 40 : 5 : 45 (i.e. 100 μL DMSO → 400 μLPEG300 → 50 μL Tween 80 → 450 μL Saline) Injection Formulation 3: DMSO : Corn oil = 10 : 90 (i.e. 100 μL DMSO → 900 μL Corn oil) Example: Take the Injection Formulation 3 (DMSO : Corn oil = 10 : 90) as an example, if 1 mL of 2.5 mg/mL working solution is to be prepared, you can take 100 μL 25 mg/mL DMSO stock solution and add to 900 μL corn oil, mix well to obtain a clear or suspension solution (2.5 mg/mL, ready for use in animals). Injection Formulation 4: DMSO : 20% SBE-β-CD in saline = 10 : 90 [i.e. 100 μL DMSO → 900 μL (20% SBE-β-CD in saline)] *Preparation of 20% SBE-β-CD in Saline (4°C，1 week): Dissolve 2 g SBE-β-CD in 10 mL saline to obtain a clear solution. Injection Formulation 5: 2-Hydroxypropyl-β-cyclodextrin : Saline = 50 : 50 (i.e. 500 μL 2-Hydroxypropyl-β-cyclodextrin → 500 μL Saline) Injection Formulation 6: DMSO : PEG300 : castor oil : Saline = 5 : 10 : 20 : 65 (i.e. 50 μL DMSO → 100 μLPEG300 → 200 μL castor oil → 650 μL Saline) Injection Formulation 7: Ethanol : Cremophor : Saline = 10： 10 : 80 (i.e. 100 μL Ethanol → 100 μL Cremophor → 800 μL Saline) Injection Formulation 8: Dissolve in Cremophor/Ethanol (50 : 50), then diluted by Saline Injection Formulation 9: EtOH : Corn oil = 10 : 90 (i.e. 100 μL EtOH → 900 μL Corn oil) Injection Formulation 10: EtOH : PEG300：Tween 80 : Saline = 10 : 40 : 5 : 45 (i.e. 100 μL EtOH → 400 μLPEG300 → 50 μL Tween 80 → 450 μL Saline) Oral Formulations Oral Formulation 1: Suspend in 0.5% CMC Na (carboxymethylcellulose sodium) Oral Formulation 2: Suspend in 0.5% Carboxymethyl cellulose Example: Take the Oral Formulation 1 (Suspend in 0.5% CMC Na) as an example, if 100 mL of 2.5 mg/mL working solution is to be prepared, you can first prepare 0.5% CMC Na solution by measuring 0.5 g CMC Na and dissolve it in 100 mL ddH2O to obtain a clear solution; then add 250 mg of the product to 100 mL 0.5% CMC Na solution, to make the suspension solution (2.5 mg/mL, ready for use in animals). Oral Formulation 3: Dissolved in PEG400 Oral Formulation 4: Suspend in 0.2% Carboxymethyl cellulose Oral Formulation 5: Dissolve in 0.25% Tween 80 and 0.5% Carboxymethyl cellulose Oral Formulation 6: Mixing with food powders Note: Please be aware that the above formulations are for reference only. InvivoChem strongly recommends customers to read literature methods/protocols carefully before determining which formulation you should use for in vivo studies, as different compounds have different solubility properties and have to be formulated differently.  (Please use freshly prepared in vivo formulations for optimal results.)

Preparing Stock Solutions		1 mg	5 mg	10 mg
	1 mM	1.8934 mL	9.4668 mL	18.9337 mL
	5 mM	0.3787 mL	1.8934 mL	3.7867 mL
	10 mM	0.1893 mL	0.9467 mL	1.8934 mL

*Note: Please select an appropriate solvent for the preparation of stock solution based on your experiment needs. For most products, DMSO can be used for preparing stock solutions (e.g. 5 mM, 10 mM, or 20 mM concentration); some products with high aqueous solubility may be dissolved in water directly. Solubility information is available at the above Solubility Data section. Once the stock solution is prepared, aliquot it to routine usage volumes and store at -20°C or -80°C. Avoid repeated freeze and thaw cycles.
