Physicochemical Properties
| Molecular Formula | C19H18N6O2 |
| Molecular Weight | 362.39 |
| Related CAS # | AKN-028;1175017-90-9 |
| Appearance | Brown to orange solid powder |
| HS Tariff Code | 2934.99.9001 |
| Storage |
Powder-20°C 3 years 4°C 2 years In solvent -80°C 6 months -20°C 1 month Note: Please store this product in a sealed and protected environment, avoid exposure to moisture. |
| Shipping Condition | Room temperature (This product is stable at ambient temperature for a few days during ordinary shipping and time spent in Customs) |
Biological Activity
| Targets | IC50: 6 nM (FLT3), 140 nM (CLK1), 220 nM (RPS6KA), 520 nM (VEGFR2), and 120 nM (FGFR2)[1] |
| ln Vitro | In a dose-dependent way, AKN-028 (0.1 nM-100 μM; 15 hours) acetate inhibits FLT3 and KIT autophosphorylation in mouse embryonic fibroblasts and human acute megakaryocytic leukemia M07 cells [1]. Tumor cell lines; AKN-028 (10 μM; 72 hours) Acetate is cytotoxic to AML cell lines and causes the MV4-11 AML cell line to undergo apoptosis [1]. |
| ln Vivo | AKN-028: male C57 black mice with MV4-11 xenografts, 15 mg/kg, ih, twice daily for 6 days) Acetate stops mouse primary AML and MV4-11 cells from growing [1]. |
| Cell Assay |
Cell Cytotoxicity Assay[1] Cell Types: Tumor cell lines Tested Concentrations: 10 μM Incubation Duration: 72 hrs (hours) Experimental Results: Had cytotoxic activity was highest in MV4-11 and MOLM-13(IC50<50 nM), followed by the three other AML cells lines(IC50=0.5-6 μM). Western Blot Analysis[1] Cell Types: Mouse embryonal fibroblasts either overexpressing FLT-wt, FLT3-TKD or FLT3-ITD and human acute megakaryoblastic leukemia M07 cells overexpressing KIT Tested Concentrations: 0.1 nM-100 μM Incubation Duration: 15 hrs (hours) Experimental Results: Inhibited FLT3 and KIT autophosphorylation. |
| Animal Protocol |
Animal/Disease Models: Male C57 black mice with MV4-11 xenografts[1] Doses: 15 mg/kg Route of Administration: subcutaneous (sc) injection; twice (two times) daily, for 6 days Experimental Results: Inhibited tumor growth and did not affect body weight. |
| References |
[1]. The Novel Tyrosine Kinase Inhibitor AKN-028 Has Significant Antileukemic Activity in Cell Lines and Primary Cultures of Acute Myeloid Leukemia. Blood Cancer J. 2012 Aug 3;2(8):e81. |
Solubility Data
| Solubility (In Vitro) | DMSO :~100 mg/mL (~275.95 mM) |
| Solubility (In Vivo) |
Note: Listed below are some common formulations that may be used to formulate products with low water solubility (e.g. < 1 mg/mL), you may test these formulations using a minute amount of products to avoid loss of samples. Injection Formulations (e.g. IP/IV/IM/SC) Injection Formulation 1: DMSO : Tween 80： Saline = 10 : 5 : 85 (i.e. 100 μL DMSO stock solution → 50 μL Tween 80 → 850 μL Saline) *Preparation of saline: Dissolve 0.9 g of sodium chloride in 100 mL ddH ₂ O to obtain a clear solution. Injection Formulation 2: DMSO : PEG300 ：Tween 80 : Saline = 10 : 40 : 5 : 45 (i.e. 100 μL DMSO → 400 μLPEG300 → 50 μL Tween 80 → 450 μL Saline) Injection Formulation 3: DMSO : Corn oil = 10 : 90 (i.e. 100 μL DMSO → 900 μL Corn oil) Example: Take the Injection Formulation 3 (DMSO : Corn oil = 10 : 90) as an example, if 1 mL of 2.5 mg/mL working solution is to be prepared, you can take 100 μL 25 mg/mL DMSO stock solution and add to 900 μL corn oil, mix well to obtain a clear or suspension solution (2.5 mg/mL, ready for use in animals). Injection Formulation 4: DMSO : 20% SBE-β-CD in saline = 10 : 90 [i.e. 100 μL DMSO → 900 μL (20% SBE-β-CD in saline)] *Preparation of 20% SBE-β-CD in Saline (4°C，1 week): Dissolve 2 g SBE-β-CD in 10 mL saline to obtain a clear solution. Injection Formulation 5: 2-Hydroxypropyl-β-cyclodextrin : Saline = 50 : 50 (i.e. 500 μL 2-Hydroxypropyl-β-cyclodextrin → 500 μL Saline) Injection Formulation 6: DMSO : PEG300 : castor oil : Saline = 5 : 10 : 20 : 65 (i.e. 50 μL DMSO → 100 μLPEG300 → 200 μL castor oil → 650 μL Saline) Injection Formulation 7: Ethanol : Cremophor : Saline = 10： 10 : 80 (i.e. 100 μL Ethanol → 100 μL Cremophor → 800 μL Saline) Injection Formulation 8: Dissolve in Cremophor/Ethanol (50 : 50), then diluted by Saline Injection Formulation 9: EtOH : Corn oil = 10 : 90 (i.e. 100 μL EtOH → 900 μL Corn oil) Injection Formulation 10: EtOH : PEG300：Tween 80 : Saline = 10 : 40 : 5 : 45 (i.e. 100 μL EtOH → 400 μLPEG300 → 50 μL Tween 80 → 450 μL Saline) Oral Formulations Oral Formulation 1: Suspend in 0.5% CMC Na (carboxymethylcellulose sodium) Oral Formulation 2: Suspend in 0.5% Carboxymethyl cellulose Example: Take the Oral Formulation 1 (Suspend in 0.5% CMC Na) as an example, if 100 mL of 2.5 mg/mL working solution is to be prepared, you can first prepare 0.5% CMC Na solution by measuring 0.5 g CMC Na and dissolve it in 100 mL ddH2O to obtain a clear solution; then add 250 mg of the product to 100 mL 0.5% CMC Na solution, to make the suspension solution (2.5 mg/mL, ready for use in animals). Oral Formulation 3: Dissolved in PEG400 Oral Formulation 4: Suspend in 0.2% Carboxymethyl cellulose Oral Formulation 5: Dissolve in 0.25% Tween 80 and 0.5% Carboxymethyl cellulose Oral Formulation 6: Mixing with food powders Note: Please be aware that the above formulations are for reference only. InvivoChem strongly recommends customers to read literature methods/protocols carefully before determining which formulation you should use for in vivo studies, as different compounds have different solubility properties and have to be formulated differently. (Please use freshly prepared in vivo formulations for optimal results.) |
| Preparing Stock Solutions | 1 mg | 5 mg | 10 mg | |
| 1 mM | 2.7595 mL | 13.7973 mL | 27.5946 mL | |
| 5 mM | 0.5519 mL | 2.7595 mL | 5.5189 mL | |
| 10 mM | 0.2759 mL | 1.3797 mL | 2.7595 mL |
