Sulfo-NHS-LC-Biotin sodium can be used for antibody labeling through amine reactions.

Physicochemical Properties

Molecular Formula	C20H29N4NAO9S2
Molecular Weight	556.59
Exact Mass	556.127
CAS #	191671-46-2
PubChem CID	71571497
Appearance	White to yellow solid powder
LogP	1.586
Hydrogen Bond Donor Count	3
Hydrogen Bond Acceptor Count	10
Rotatable Bond Count	14
Heavy Atom Count	36
Complexity	959
Defined Atom Stereocenter Count	3
SMILES	C1[C@H]2[C@@H]([C@@H](S1)CCCCC(=O)NCCCCCC(=O)ON3C(=O)CC(C3=O)S(=O)(=O)[O-])NC(=O)N2.[Na+]
InChi Key	JJGWLCLUQNFDIS-GTSONSFRSA-M
InChi Code	InChI=1S/C20H30N4O9S2.Na/c25-15(7-4-3-6-13-18-12(11-34-13)22-20(29)23-18)21-9-5-1-2-8-17(27)33-24-16(26)10-14(19(24)28)35(30,31)32;/h12-14,18H,1-11H2,(H,21,25)(H2,22,23,29)(H,30,31,32);/q;+1/p-1/t12-,13-,14?,18-;/m0./s1
Chemical Name	sodium;1-[6-[5-[(3aS,4S,6aR)-2-oxo-1,3,3a,4,6,6a-hexahydrothieno[3,4-d]imidazol-4-yl]pentanoylamino]hexanoyloxy]-2,5-dioxopyrrolidine-3-sulfonate
HS Tariff Code	2934.99.9001
Storage	Powder-20°C 3 years 4°C 2 years In solvent -80°C 6 months -20°C 1 month Note: Please store this product in a sealed and protected environment, avoid exposure to moisture.
Shipping Condition	Room temperature (This product is stable at ambient temperature for a few days during ordinary shipping and time spent in Customs)

Biological Activity

References

[1]. A Novel Intravascular Drug Delivery Method Using Endothelial Biotinylation and Avidin-Biotin Binding. Drug Deliv. Oct-Dec 2001;8(4):215-22.

Solubility Data

Solubility (In Vitro)

DMSO: 83.33 mg/mL (149.72 mM) H2O: 20 mg/mL (35.93 mM）

Solubility (In Vivo)

Solubility in Formulation 1: ≥ 2.08 mg/mL (3.74 mM) (saturation unknown) in 10% DMSO + 40% PEG300 + 5% Tween80 + 45% Saline (add these co-solvents sequentially from left to right, and one by one), clear solution. For example, if 1 mL of working solution is to be prepared, you can add 100 μL of 20.8 mg/mL clear DMSO stock solution to 400 μL PEG300 and mix evenly; then add 50 μL Tween-80 to the above solution and mix evenly; then add 450 μL normal saline to adjust the volume to 1 mL. Preparation of saline: Dissolve 0.9 g of sodium chloride in 100 mL ddH₂ O to obtain a clear solution. Solubility in Formulation 2: ≥ 2.08 mg/mL (3.74 mM) (saturation unknown) in 10% DMSO + 90% (20% SBE-β-CD in Saline) (add these co-solvents sequentially from left to right, and one by one), clear solution. For example, if 1 mL of working solution is to be prepared, you can add 100 μL of 20.8 mg/mL clear DMSO stock solution to 900 μL of 20% SBE-β-CD physiological saline solution and mix evenly. Preparation of 20% SBE-β-CD in Saline (4°C，1 week): Dissolve 2 g SBE-β-CD in 10 mL saline to obtain a clear solution. Solubility in Formulation 3: ≥ 2.08 mg/mL (3.74 mM) (saturation unknown) in 10% DMSO + 90% Corn Oil (add these co-solvents sequentially from left to right, and one by one), clear solution. For example, if 1 mL of working solution is to be prepared, you can add 100 μL of 20.8 mg/mL clear DMSO stock solution to 900 μL of corn oil and mix evenly.  (Please use freshly prepared in vivo formulations for optimal results.)

Preparing Stock Solutions		1 mg	5 mg	10 mg
	1 mM	1.7967 mL	8.9833 mL	17.9665 mL
	5 mM	0.3593 mL	1.7967 mL	3.5933 mL
	10 mM	0.1797 mL	0.8983 mL	1.7967 mL

*Note: Please select an appropriate solvent for the preparation of stock solution based on your experiment needs. For most products, DMSO can be used for preparing stock solutions (e.g. 5 mM, 10 mM, or 20 mM concentration); some products with high aqueous solubility may be dissolved in water directly. Solubility information is available at the above Solubility Data section. Once the stock solution is prepared, aliquot it to routine usage volumes and store at -20°C or -80°C. Avoid repeated freeze and thaw cycles.
