OF-C4-Deg-Lin is an ionizable lipid with varying linker lengths. OF-C4-Deg-Lin may be utilized to generate lipid nanoparticles (LNPs) for delivery of siRNA and mRNA.

Physicochemical Properties

Molecular Formula	C100H176N4O10
Molecular Weight	1594.48827171326
Exact Mass	1594.342
CAS #	2383003-60-7
PubChem CID	168006879
Appearance	Colorless to light yellow viscous liquid
LogP	30.6
Hydrogen Bond Donor Count	2
Hydrogen Bond Acceptor Count	12
Rotatable Bond Count	90
Heavy Atom Count	114
Complexity	2160
Defined Atom Stereocenter Count	2
SMILES	CCCCC/C=C\C/C=C\CCCCCCCC(=O)OCCCCN(CCCCOC(=O)CCCCCCC/C=C\C/C=C\CCCCC)CCCC[C@@H]1NC(=O)[C@@H](NC1=O)CCCCN(CCCCOC(=O)CCCCCCC/C=C\C/C=C\CCCCC)CCCCOC(=O)CCCCCCC/C=C\C/C=C\CCCCC
InChi Key	ZQXDXCNSODVUPG-ACIWIILCSA-N
InChi Code	InChI=1S/C100H176N4O10/c1-5-9-13-17-21-25-29-33-37-41-45-49-53-57-61-79-95(105)111-89-73-69-85-103(86-70-74-90-112-96(106)80-62-58-54-50-46-42-38-34-30-26-22-18-14-10-6-2)83-67-65-77-93-99(109)102-94(100(110)101-93)78-66-68-84-104(87-71-75-91-113-97(107)81-63-59-55-51-47-43-39-35-31-27-23-19-15-11-7-3)88-72-76-92-114-98(108)82-64-60-56-52-48-44-40-36-32-28-24-20-16-12-8-4/h21-28,33-40,93-94H,5-20,29-32,41-92H2,1-4H3,(H,101,110)(H,102,109)/b25-21-,26-22-,27-23-,28-24-,37-33-,38-34-,39-35-,40-36-/t93-,94-/m0/s1
Chemical Name	4-[4-[(2S,5S)-5-[4-[bis[4-[(9Z,12Z)-octadeca-9,12-dienoyl]oxybutyl]amino]butyl]-3,6-dioxopiperazin-2-yl]butyl-[4-[(9Z,12Z)-octadeca-9,12-dienoyl]oxybutyl]amino]butyl (9Z,12Z)-octadeca-9,12-dienoate
HS Tariff Code	2934.99.9001
Storage	Powder-20°C 3 years 4°C 2 years In solvent -80°C 6 months -20°C 1 month
Shipping Condition	Room temperature (This product is stable at ambient temperature for a few days during ordinary shipping and time spent in Customs)

Biological Activity

References

[1]. Customizable Lipid Nanoparticle Materials for the Delivery of siRNAs and mRNAs. Angew Chem Int Ed Engl. 2018 Oct 8;57(41):13582-13586.

Solubility Data

Solubility (In Vitro)

DMSO: 100 mg/mL (62.72 mM)

Solubility (In Vivo)

Solubility in Formulation 1: ≥ 2.5 mg/mL (1.57 mM) (saturation unknown) in 10% DMSO + 40% PEG300 +5% Tween-80 + 45% Saline (add these co-solvents sequentially from left to right, and one by one), clear solution. For example, if 1 mL of working solution is to be prepared, you can add 100 μL of 25.0 mg/mL clear DMSO stock solution to 400 μL PEG300 and mix evenly; then add 50 μL Tween-80 + to the above solution and mix evenly; then add 450 μL normal saline to adjust the volume to 1 mL. Preparation of saline: Dissolve 0.9 g of sodium chloride in 100 mL ddH₂ O to obtain a clear solution.  (Please use freshly prepared in vivo formulations for optimal results.)

Preparing Stock Solutions		1 mg	5 mg	10 mg
	1 mM	0.6272 mL	3.1358 mL	6.2716 mL
	5 mM	0.1254 mL	0.6272 mL	1.2543 mL
	10 mM	0.0627 mL	0.3136 mL	0.6272 mL

*Note: Please select an appropriate solvent for the preparation of stock solution based on your experiment needs. For most products, DMSO can be used for preparing stock solutions (e.g. 5 mM, 10 mM, or 20 mM concentration); some products with high aqueous solubility may be dissolved in water directly. Solubility information is available at the above Solubility Data section. Once the stock solution is prepared, aliquot it to routine usage volumes and store at -20°C or -80°C. Avoid repeated freeze and thaw cycles.
