GNF-6231 1243244-74-7_Others_Signaling Pathways_Products

GNF-6231 is a novel, potent, orally active and selective Porcupine inhibitor that blocks Wnt signaling with IC50 of 0.8 nM (Wnt3a Co-culture RGA). GNF-6231 has low/no drug drug interaction potential with IC50s of greater than 10 μM on all CYP isoforms tested. GNF-6231 showed excellent pathway inhibition and induced robust antitumor efficacy in a mouse MMTV-WNT1 xenograft tumor model. Targeting the aberrant Wnt signaling pathway is an attractive approach for the treatment of various cancers. Wnt signaling is tightly controlled during cellular proliferation, differentiation, and embryonic morphogenesis. Aberrant activation of this pathway plays a critical role in a variety of cancers including cutaneous squamous cell carcinoma (SCC), breast cancer, and colorectal cancer.

Physicochemical Properties

Molecular Formula

C25H28N6O2

Molecular Weight

444.528824806213

Exact Mass

444.227

CAS #

1243244-74-7

Related CAS #

1243245-18-2

PubChem CID

46927217

Appearance

White to off-white solid powder

LogP

1.6

Hydrogen Bond Donor Count

Hydrogen Bond Acceptor Count

Rotatable Bond Count

Heavy Atom Count

Complexity

667

Defined Atom Stereocenter Count

SMILES

O=C(C)N1CCN(C2C=NC(=CC=2)NC(CC2=CN=C(C3C=CN=C(C)C=3)C(C)=C2)=O)CC1

InChi Key

NEQNTAAQXJOQOM-UHFFFAOYSA-N

InChi Code

InChI=1S/C25H28N6O2/c1-17-12-20(15-28-25(17)21-6-7-26-18(2)13-21)14-24(33)29-23-5-4-22(16-27-23)31-10-8-30(9-11-31)19(3)32/h4-7,12-13,15-16H,8-11,14H2,1-3H3,(H,27,29,33)

Chemical Name

N-(5-(4-acetylpiperazin-1-yl)pyridin-2-yl)-2-(2'',3-dimethyl-[2,4''-bipyridin]-5-yl)acetamide

Synonyms

GNF6231; GNF 6231; GNF-6231

HS Tariff Code

2934.99.9001

Storage

Powder-20°C 3 years

4°C 2 years

In solvent -80°C 6 months

-20°C 1 month

Shipping Condition

Room temperature (This product is stable at ambient temperature for a few days during ordinary shipping and time spent in Customs)

Biological Activity

ln Vitro

In vitro activity: As an orally active and selective Porcupine inhibitor, GNF-6231 has no appreciable activities, at least up to 10 μM testing concentrations, for more than 200 off-targets, which include GPCRs, kinases, proteases, transporters, ion channels, and nuclear receptors. GNF-6231 shows IC50s of greater than 10 μM on all CYP isoforms tested (2C9, 2D6, 3A4). It shows high permeability in a Caco-2 human cell permeability assay with a possible efflux.

Kinase Assay: GNF-6231 is a potent and selective Porcupine inhibitor with an IC50 of 0.8 nM.

Cell Assay: the TM3 Wnt-Luc and L-cell Wnt3A cells are co-cultured in a 384-well plate with DMEM supplemented with 2% (vol/vol) FBS and treated with different concentrations of compounds. After 24 h, the firefly luciferase activities are assayed with the Bright-Glo Luciferase Assay System. The IC50 is measured when the effect of the compound reduces the luminescence signal by 50%.

ln Vivo

GNF-6231 displays excellent pathway inhibition and induces robust antitumor efficacy in a mouse MMTV-WNT1 xenograft tumor model. GNF-6231 is moderately bound to mouse, rat, dog, monkey, and human plasma proteins (88.0, 83.1, 90.9, 71.2, and 95%, respectively). It shows good oral bioavailability, ranging from 72 to 96% in preclinical species (mouse, rat, and dog) when dosed in solution formulations. GNF-6231 is expected to have minimal to marginal distribution to tissues compared to total body water following intravenous administration to mouse (Vss 0.57 L/kg), rat (Vss 0.70 L/kg), and dog (Vss 0.25 L/kg).

Animal Protocol

Dissolved in 20% (vol/vol) PEG300 and 30% (vol/vol) 10% ETPGS in water; 3 mg/kg; p.o.

Nude mice

References

ACS Med Chem Lett.2016 May 10;7(7):676-80.

Solubility Data

Solubility (In Vitro)

DMSO: 90mg/mL

Water:5 mg/mL

Ethanol:< 1 mg/mL

Solubility (In Vivo)

Note: Listed below are some common formulations that may be used to formulate products with low water solubility (e.g. < 1 mg/mL), you may test these formulations using a minute amount of products to avoid loss of samples.

Injection Formulations
(e.g. IP/IV/IM/SC) Injection Formulation 1: DMSO : Tween 80： Saline = 10 : 5 : 85 (i.e. 100 μL DMSO stock solution → 50 μL Tween 80 → 850 μL Saline)
*Preparation of saline: Dissolve 0.9 g of sodium chloride in 100 mL ddH ₂ O to obtain a clear solution.
Injection Formulation 2: DMSO : PEG300 ：Tween 80 : Saline = 10 : 40 : 5 : 45 (i.e. 100 μL DMSO → 400 μLPEG300 → 50 μL Tween 80 → 450 μL Saline)
Injection Formulation 3: DMSO : Corn oil = 10 : 90 (i.e. 100 μL DMSO → 900 μL Corn oil)
Example: Take the Injection Formulation 3 (DMSO : Corn oil = 10 : 90) as an example, if 1 mL of 2.5 mg/mL working solution is to be prepared, you can take 100 μL 25 mg/mL DMSO stock solution and add to 900 μL corn oil, mix well to obtain a clear or suspension solution (2.5 mg/mL, ready for use in animals).
Injection Formulation 4: DMSO : 20% SBE-β-CD in saline = 10 : 90 [i.e. 100 μL DMSO → 900 μL (20% SBE-β-CD in saline)]
*Preparation of 20% SBE-β-CD in Saline (4°C，1 week): Dissolve 2 g SBE-β-CD in 10 mL saline to obtain a clear solution.
Injection Formulation 5: 2-Hydroxypropyl-β-cyclodextrin : Saline = 50 : 50 (i.e. 500 μL 2-Hydroxypropyl-β-cyclodextrin → 500 μL Saline)
Injection Formulation 6: DMSO : PEG300 : castor oil : Saline = 5 : 10 : 20 : 65 (i.e. 50 μL DMSO → 100 μLPEG300 → 200 μL castor oil → 650 μL Saline)
Injection Formulation 7: Ethanol : Cremophor : Saline = 10： 10 : 80 (i.e. 100 μL Ethanol → 100 μL Cremophor → 800 μL Saline)
Injection Formulation 8: Dissolve in Cremophor/Ethanol (50 : 50), then diluted by Saline
Injection Formulation 9: EtOH : Corn oil = 10 : 90 (i.e. 100 μL EtOH → 900 μL Corn oil)
Injection Formulation 10: EtOH : PEG300：Tween 80 : Saline = 10 : 40 : 5 : 45 (i.e. 100 μL EtOH → 400 μLPEG300 → 50 μL Tween 80 → 450 μL Saline)

Oral Formulations Oral Formulation 1: Suspend in 0.5% CMC Na (carboxymethylcellulose sodium)
Oral Formulation 2: Suspend in 0.5% Carboxymethyl cellulose
Example: Take the Oral Formulation 1 (Suspend in 0.5% CMC Na) as an example, if 100 mL of 2.5 mg/mL working solution is to be prepared, you can first prepare 0.5% CMC Na solution by measuring 0.5 g CMC Na and dissolve it in 100 mL ddH2O to obtain a clear solution; then add 250 mg of the product to 100 mL 0.5% CMC Na solution, to make the suspension solution (2.5 mg/mL, ready for use in animals).
Oral Formulation 3: Dissolved in PEG400
Oral Formulation 4: Suspend in 0.2% Carboxymethyl cellulose
Oral Formulation 5: Dissolve in 0.25% Tween 80 and 0.5% Carboxymethyl cellulose
Oral Formulation 6: Mixing with food powders

Note: Please be aware that the above formulations are for reference only. InvivoChem strongly recommends customers to read literature methods/protocols carefully before determining which formulation you should use for in vivo studies, as different compounds have different solubility properties and have to be formulated differently.

(Please use freshly prepared in vivo formulations for optimal results.)

Preparing Stock Solutions		1 mg	5 mg	10 mg
	1 mM	2.2496 mL	11.2478 mL	22.4957 mL
	5 mM	0.4499 mL	2.2496 mL	4.4991 mL
	10 mM	0.2250 mL	1.1248 mL	2.2496 mL

*Note: Please select an appropriate solvent for the preparation of stock solution based on your experiment needs. For most products, DMSO can be used for preparing stock solutions (e.g. 5 mM, 10 mM, or 20 mM concentration); some products with high aqueous solubility may be dissolved in water directly. Solubility information is available at the above Solubility Data section. Once the stock solution is prepared, aliquot it to routine usage volumes and store at -20°C or -80°C. Avoid repeated freeze and thaw cycles.
