DSPE-PEG 2000 is a PEG liposome that may be utilized to form micelles as nanoparticles for drug delivery.

Physicochemical Properties

Molecular Formula	C44H86NO11P
Molecular Weight	836.127516269684
Exact Mass	835.593
CAS #	892144-24-0
Related CAS #	DSPE-PEG;145035-96-7
PubChem CID	122632359
Appearance	White to off-white solid powder
LogP	14.7
Hydrogen Bond Donor Count	3
Hydrogen Bond Acceptor Count	11
Rotatable Bond Count	47
Heavy Atom Count	57
Complexity	971
Defined Atom Stereocenter Count	0
SMILES	P(=O)(O)(OCCNC(=O)OCCO)OCC(COC(CCCCCCCCCCCCCCCCC)=O)OC(CCCCCCCCCCCCCCCCC)=O
InChi Key	BPZILUVAHZTEEE-UHFFFAOYSA-N
InChi Code	InChI=1S/C44H86NO11P/c1-3-5-7-9-11-13-15-17-19-21-23-25-27-29-31-33-42(47)53-39-41(40-55-57(50,51)54-37-35-45-44(49)52-38-36-46)56-43(48)34-32-30-28-26-24-22-20-18-16-14-12-10-8-6-4-2/h41,46H,3-40H2,1-2H3,(H,45,49)(H,50,51)
Chemical Name	[3-[hydroxy-[2-(2-hydroxyethoxycarbonylamino)ethoxy]phosphoryl]oxy-2-octadecanoyloxypropyl] octadecanoate
HS Tariff Code	2934.99.9001
Storage	Powder-20°C 3 years 4°C 2 years In solvent -80°C 6 months -20°C 1 month
Shipping Condition	Room temperature (This product is stable at ambient temperature for a few days during ordinary shipping and time spent in Customs)

Biological Activity

References

[1]. Effect of the lipid chain melting transition on the stability of DSPE-PEG(2000) micelles. Langmuir. 2009 Jul 7;25(13):7279-86.

Solubility Data

Solubility (In Vitro)

DMSO : ~71.43 mg/mL

Solubility (In Vivo)

Solubility in Formulation 1: ≥ 2.5 mg/mL (Infinity mM) (saturation unknown) in 10% DMSO + 40% PEG300 + 5% Tween80 + 45% Saline (add these co-solvents sequentially from left to right, and one by one), clear solution. For example, if 1 mL of working solution is to be prepared, you can add 100 μL of 25.0 mg/mL clear DMSO stock solution to 400 μL PEG300 and mix evenly; then add 50 μL Tween-80 to the above solution and mix evenly; then add 450 μL normal saline to adjust the volume to 1 mL. Preparation of saline: Dissolve 0.9 g of sodium chloride in 100 mL ddH₂ O to obtain a clear solution. Solubility in Formulation 2: ≥ 2.5 mg/mL (Infinity mM) (saturation unknown) in 10% DMSO + 90% (20% SBE-β-CD in Saline) (add these co-solvents sequentially from left to right, and one by one), clear solution. For example, if 1 mL of working solution is to be prepared, you can add 100 μL of 25.0 mg/mL clear DMSO stock solution to 900 μL of 20% SBE-β-CD physiological saline solution and mix evenly. Preparation of 20% SBE-β-CD in Saline (4°C，1 week): Dissolve 2 g SBE-β-CD in 10 mL saline to obtain a clear solution.  (Please use freshly prepared in vivo formulations for optimal results.)

Preparing Stock Solutions		1 mg	5 mg	10 mg
	1 mM	1.1960 mL	5.9799 mL	11.9599 mL
	5 mM	0.2392 mL	1.1960 mL	2.3920 mL
	10 mM	0.1196 mL	0.5980 mL	1.1960 mL

*Note: Please select an appropriate solvent for the preparation of stock solution based on your experiment needs. For most products, DMSO can be used for preparing stock solutions (e.g. 5 mM, 10 mM, or 20 mM concentration); some products with high aqueous solubility may be dissolved in water directly. Solubility information is available at the above Solubility Data section. Once the stock solution is prepared, aliquot it to routine usage volumes and store at -20°C or -80°C. Avoid repeated freeze and thaw cycles.
