Physicochemical Properties
| Molecular Formula | C22H22N8O |
| Molecular Weight | 414.46 |
| Appearance | Typically exists as solid at room temperature |
| HS Tariff Code | 2934.99.9001 |
| Storage |
Powder-20°C 3 years 4°C 2 years In solvent -80°C 6 months -20°C 1 month |
| Shipping Condition | Room temperature (This product is stable at ambient temperature for a few days during ordinary shipping and time spent in Customs) |
Biological Activity
| ln Vitro | DNA-PK-IN-13 exhibited the best antiproliferative activity in Jurkat (T lymphoma) cells with IC50 = 0.6 μM[1]. DNA-PK-IN-13 (0.1-40 μM; 10 minutes) concentration-dependently reduced the expression level of γH2A.X in Jurkat cells and HepG2 cells[1]. The combination of DNA-PK-IN-13 (1 μM; 24 hours) and doxorubicin (HY-15142A) (0.1 μM) significantly reduced the proportion of S phase of Jurkat cell cycle and increased the proportion of G2/M phase[1]. |
| ln Vivo | DNA-PK-IN-13 has good oral bioavailability (F = 31.8%)[1]. |
| Cell Assay |
Western Blot Analysis[1] Cell Types: HepG2 cells, Jurkat Tested Concentrations: 0.1; 0.5; 5; 10; 20; 40μM Incubation Duration: 10min Experimental Results: Concentration-dependently decreased the expression level of γH2A.X in Jurkat cells and HepG2 cells. DNA-PK-IN-13 can affect the production of γH2A.X and thus inhibit DNA damage repair. Cell Cycle Analysis[1] Cell Types: Jurkat Tested Concentrations: 1μM; Dox 0.1μM Incubation Duration: 24h Experimental Results: DNA-PK-IN-13 alone did not demonstrate statistically significant differences in the cell cycle. However, when combined with doxorubicin, DNA-PK-IN-13 influenced the cell cycle, contributing to cell death. |
| Animal Protocol |
Animal/Disease Models:CT26 colon cancer mouse [1] Doses: 10 mg/kg single dose Route of Administration: i.p Experimental Results: Single-agent treatment reduced tumor weight by 30.8% and tumor volume by 32.1%. Co-administration with doxorubicin (2.5 mg/kg) produced more significant tumor inhibitory activity, with a TGI of 50.2%. No significant weight loss or deaths were observed. |
| References |
[1]. Cheng B, Y et al. Discovery of Novel Heterotricyclic Compounds as DNA-Dependent Protein Kinase (DNA-PK) Inhibitors with Enhanced Chemosensitivity, Oral Bioavailability, and the Ability to Potentiate Cancer Immunotherapy. J Med Chem. 2024 Apr 25;67(8):6253-6267 |
Solubility Data
| Solubility (In Vitro) | May dissolve in DMSO (in most cases), if not, try other solvents such as H2O, Ethanol, or DMF with a minute amount of products to avoid loss of samples |
| Solubility (In Vivo) |
Note: Listed below are some common formulations that may be used to formulate products with low water solubility (e.g. < 1 mg/mL), you may test these formulations using a minute amount of products to avoid loss of samples. Injection Formulations (e.g. IP/IV/IM/SC) Injection Formulation 1: DMSO : Tween 80： Saline = 10 : 5 : 85 (i.e. 100 μL DMSO stock solution → 50 μL Tween 80 → 850 μL Saline) *Preparation of saline: Dissolve 0.9 g of sodium chloride in 100 mL ddH ₂ O to obtain a clear solution. Injection Formulation 2: DMSO : PEG300 ：Tween 80 : Saline = 10 : 40 : 5 : 45 (i.e. 100 μL DMSO → 400 μLPEG300 → 50 μL Tween 80 → 450 μL Saline) Injection Formulation 3: DMSO : Corn oil = 10 : 90 (i.e. 100 μL DMSO → 900 μL Corn oil) Example: Take the Injection Formulation 3 (DMSO : Corn oil = 10 : 90) as an example, if 1 mL of 2.5 mg/mL working solution is to be prepared, you can take 100 μL 25 mg/mL DMSO stock solution and add to 900 μL corn oil, mix well to obtain a clear or suspension solution (2.5 mg/mL, ready for use in animals). Injection Formulation 4: DMSO : 20% SBE-β-CD in saline = 10 : 90 [i.e. 100 μL DMSO → 900 μL (20% SBE-β-CD in saline)] *Preparation of 20% SBE-β-CD in Saline (4°C，1 week): Dissolve 2 g SBE-β-CD in 10 mL saline to obtain a clear solution. Injection Formulation 5: 2-Hydroxypropyl-β-cyclodextrin : Saline = 50 : 50 (i.e. 500 μL 2-Hydroxypropyl-β-cyclodextrin → 500 μL Saline) Injection Formulation 6: DMSO : PEG300 : castor oil : Saline = 5 : 10 : 20 : 65 (i.e. 50 μL DMSO → 100 μLPEG300 → 200 μL castor oil → 650 μL Saline) Injection Formulation 7: Ethanol : Cremophor : Saline = 10： 10 : 80 (i.e. 100 μL Ethanol → 100 μL Cremophor → 800 μL Saline) Injection Formulation 8: Dissolve in Cremophor/Ethanol (50 : 50), then diluted by Saline Injection Formulation 9: EtOH : Corn oil = 10 : 90 (i.e. 100 μL EtOH → 900 μL Corn oil) Injection Formulation 10: EtOH : PEG300：Tween 80 : Saline = 10 : 40 : 5 : 45 (i.e. 100 μL EtOH → 400 μLPEG300 → 50 μL Tween 80 → 450 μL Saline) Oral Formulations Oral Formulation 1: Suspend in 0.5% CMC Na (carboxymethylcellulose sodium) Oral Formulation 2: Suspend in 0.5% Carboxymethyl cellulose Example: Take the Oral Formulation 1 (Suspend in 0.5% CMC Na) as an example, if 100 mL of 2.5 mg/mL working solution is to be prepared, you can first prepare 0.5% CMC Na solution by measuring 0.5 g CMC Na and dissolve it in 100 mL ddH2O to obtain a clear solution; then add 250 mg of the product to 100 mL 0.5% CMC Na solution, to make the suspension solution (2.5 mg/mL, ready for use in animals). Oral Formulation 3: Dissolved in PEG400 Oral Formulation 4: Suspend in 0.2% Carboxymethyl cellulose Oral Formulation 5: Dissolve in 0.25% Tween 80 and 0.5% Carboxymethyl cellulose Oral Formulation 6: Mixing with food powders Note: Please be aware that the above formulations are for reference only. InvivoChem strongly recommends customers to read literature methods/protocols carefully before determining which formulation you should use for in vivo studies, as different compounds have different solubility properties and have to be formulated differently. (Please use freshly prepared in vivo formulations for optimal results.) |
| Preparing Stock Solutions | 1 mg | 5 mg | 10 mg | |
| 1 mM | 2.4128 mL | 12.0639 mL | 24.1278 mL | |
| 5 mM | 0.4826 mL | 2.4128 mL | 4.8256 mL | |
| 10 mM | 0.2413 mL | 1.2064 mL | 2.4128 mL |
